PP-4

P/N. 11106150

Modell

Farbe

  • PP-4
    P.N. 11106150

Eigenschaften

Electronics and Audio
Max Input Current16A
Max Output Current16A
LED IndicatorsPower
Power Connectors
Power Input1 x PowerCon TRUE1 (male), rear panel
Power Output4 x PowerCon TRUE1 (female), front panel
Loop1 x PowerCon TRUE1 (female), rear panel
Dimensions-Weight
Dimensions ( H x W x D )44 x 216 x 311 mm
1,7 x 8,5 x 12,2 in
Net Weight1,8 kg ( 3,9 lb )
Shipping
Carton Dimensions ( H x W x D )110 x 330 x 360 mm
4,3 x 13,0 x 14,2 in
Shipping Weight3,0 kg ( 6,6 lb )
Qualifikation Format Größe
Datenblatt
HT_PP-4_EN.pdf PDF 143 Kb
